Borescopic 3D inspection of complex geometries

von Jochen Schlobohm

120 Seiten, Taschenbuch

Kurzbeschreibung des Verlags

This work gives an overview of borescopic 3D inspection. It focuses on the use of fringe projection profilometry with a borescope for image projection and a chip-on-tip camera for image acquisition. It starts with a short history of endoscopes and covers the state of the art of 3D optical measurement and endoscopic inspection systems. The main part addresses the development of a rigid borescopic fringe projection system. The high distortion of a borescope and its flexible shaft yield new challenges towards the calibration of such a measurement system. Major contributions where made towards the analysis and compensation of aberrations caused by bending of the rigid borescope. Hence a method for orientation sensitive calibration was introduced. Additionally, the topic of calibrating a serial kinematic, used to position the measurement system relative to a specimen, is covered. Finally, this work concludes with measurement results and an outlook for further research.

• Reihe: Berichte aus dem imr
• Themen: Technologie, Ingenieurswissenschaft, Landwirtschaft, Industrieprozesse
• ISBN: 9783959002066
• Sprache: Englisch
• Erscheinungsdatum: 07.06.2018
• Größe: 21 x 14.7 cm
• Verlag: TEWISS
• Reihe herausgegeben von: Eduard Reithmeier
